PAC ROEM-FRD3 Radio Replacement Interface

Description

Facilitates the replacement of factory-installed premium sound systems in select Ford vehicles while retaining the function of the factory amplified audio system.

Features

• System interface to replace factory installed receivers and integrate factory amplifiers
• Easy Installation
• Adjustable 4-channel RCA outputs that provide Line Level Matching
• Isolated transformer inputs and outputs
• Trigger wire included
• For 1999 - 2002 Navigator, Expedition and Excursion vehicles
• Interface allows warning chimes to function
• Maintains correct phasing
• 20-20000 Hz outputs

Compatibility List:

• Ford:
• 1998 - 2002 Crown Victoria
• 1999 - 2002 Excursion
• 1999 - 2002 Expedition
• 1998 - 2002 Explorer
• 1998 - 2002 Ranger
• Lincoln:
• 1998 - 2002 Continental
• 1999 - 2002 Navigator
• Mercury:
• 1998 - 2002 Mountaineer

This ROEM Kit Includes the following:

• PAC SNI-35
• PAC RAD-UNV
• PAC AMP-FRD3

Connections:

• Yellow – 12V Constant
• Red – 12V Accessory
• Black - Ground
• Orange – Dash Light Dimmer/Illumination
• Green – Left Rear Speaker (+)
• Green with Black Stripe Left Rear Speaker (-)
• White – Left Front Speaker (+)
• White with Black Stripe – Left Front Speaker (-)
• Purple – Right Rear Speaker (+)
• Purple with Black Stripe – Right Rear Speaker (-)
• Gray – Right Front Speaker (+)
• Gray with Black Stripe – Right Front Speaker (-)
